Product Details:
|
| Product Name: | Fixed Contact | Type: | 630A/1250A/1600A/2000A/3150A/4000A |
|---|---|---|---|
| Sample: | Could Offer But Not Free | Dimension: | / |
| Material: | DMC,BMC,SMC | Operating Temperature: | 30℃~120℃ |
| Application: | Low-high Voltage Cabinet | ||
| Highlight: | T2 Copper Fixed Contact,630A Copper Fixed Contact,Vacuum Circuit Breaker Copper Fixed Contact |
||
Features:
1.Copper and aluminum combine products are new generations product.
2.The tensile and bending strength of it are outstanding, and bonding performance is also good.
3.There are no surface cracks after flattening and bending, they are the domestic new type of enery saving products currently.
4.Dynamic thermal stability, temperature rise and loop resistance are all compare favorably with the same levels of T2 copper, this is the idea products of the present electrical industry which can lower the costs.
| Product Name | Fixed contact 630a~4000a |
| Operating Temperature | -40°C~+140°C |
| Type | 630a~4000a |
| Material | Copper T2 |
| Model | Diameter | Length | Current |
| 630A 35X82 | 35 | 82 | 630A |
| 1250A 49X82 | 49 | 82 | 1250A |
| 1600A 55X82 | 55 | 82 | 1600A |
| 2000A 79X107 | 79 | 107 | 2000A |
| 3150A 109X107 | 109 | 107 | 3150A |
| 4000A 109X107 | 109 | 107 | 4000A |
